AQT-56FT, AQT-275FT, AQT-285FT, AQT-290FT, AQT-315FT & AQT-390FT

Aquatrol™ ZX-55 Filter Systems

The Aquatrol™ ZX-55 Filtration Systems are designed to deliver cleaner, safer water to every tap in your home. Using advanced zeolite media, these systems effectively reduce sediment, suspended particles, and unwanted impurities, while also helping to improve clarity and overall water quality. By filtering water at the point of entry, they provide comprehensive protection for your family, appliances, and plumbing systems.

Built for durability and long-lasting performance, Aquatrol™ ZX-55 Filter Systems feature a rugged design capable of handling demanding residential and light commercial applications. With powerful flow rates and consistent filtration, they ensure a reliable supply of fresh, clean water throughout your household. Whether used as a standalone solution or as pretreatment in a larger system, Aquatrol™ ZX-55 Filter Systems delivers dependable, heavy-duty performance for healthier water every day.

FEATURES & BENEFITS

Filter Media: AQUATROL™ – Zeolite ZX-55

Filtration Factor: 10 – 20 gpm/ft²

Backwash Factor: 14 – 18 gpm/ft²

Micron Efficiency: 3 – 5 microns

Mesh: 12 x 20

NSF: Standard 61

Density: 48 lbs/ft³

ZX-55 FILTERS SPECIFICATIONS

Part NumberValueTank SizeZX-55 (ft³)
FS-ZX55-56FT-0844AQT-56FT8" x 44"0.75
FS-ZX55-56FT-0948AQT-56FT9" x 48"1
FS-ZX55-56FT-1054AQT-56FT10" x 54"1.5
FS-ZX55-56FT-1252AQT-56FT12" x 52"1.75
FS-ZX55-56FT-1354AQT-56FT13" x 54"2
FS-ZX55-275FT-1054AQT-275FT10" x 54"2
FS-ZX55-275FT-1252AQT-275FT12" x 52"1.75
FS-ZX55-275FT-1354AQT-275FT13" x 54"2
FS-ZX55-275FT-1465AQT-275FT14" x 65"3
FS-ZX55-275FT-1665AQT-275FT16" x 65"4
FS-ZX55-275FT-1865AQT-275FT18" x 65"5
FS-ZX55-285FT-1465AQT-285FT14" x 65"3
FS-ZX55-285FT-1665AQT-285FT16" x 65"4
FS-ZX55-285FT-1865AQT-285FT18" x 65"5
FS-ZX55-285FT-2162AQT-285FT21" x 62"7
FS-ZX55-285FT-2472AQT-285FT24" x 72"10
FS-ZX55-290FT-1465AQT-290FT14" x 65"3
FS-ZX55-290FT-1665AQT-290FT16" x 65"4
FS-ZX55-290FT-1865AQT-290FT18" x 65"5
FS-ZX55-315FT-2162AQT-315FT21" x 62"7
FS-ZX55-315FT-2472AQT-315FT24" x 72"10
FS-ZX55-315FT-3072AQT-315FT30" x 72"15
FS-ZX55-315FT-3672AQT-315FT36" x 72"20
FS-ZX55-315FT-4272AQT-315FT42" x 72"30
FS-ZX55-390FT-3672AQT-390FT36" x 72"20
FS-ZX55-390FT-4272AQT-390FT42" x 72"30
FS-ZX55-390FT-4872AQT-390FT48" x 72"40

AQUATROL™ VALVES SPECIFICATIONS

ValvesInletDrainDistributorVoltageMax PressureTemperature ºF
AQT-56FT3/4" - 1"1/2"1.05"OD (3/4"CED 40)24V/60Hz120 psi34-113
AQT-275FT1"3/4"1.05"OD (3/4"CED 40)24V/60Hz120 psi34-113
AQT-285FT1.5"1"1.96"OD (1.5"CED 40)24V/60Hz120 psi34-113
AQT-290FT2"3/4"1.96"OD (1.5"CED 40)24V/60Hz120 psi34-113
AQT-315FT2"2"2.49"OD (2"CED 40)24V/60Hz120 psi34-113
AQT-390FT3"2"3.5"OD (3"CED 40)24V/60Hz120 psi34-113

Important Note. The flow rates and characteristics of the ZX-55 are values provided by the filter media manufacturer in its data sheet. The calculations of minimum and maximum flow rates are based on this information.
For waters with special characteristics or amounts of suspended solids, please contact your supplier for more information. DLFC must be verified by the customer and/or installer to verify that they meet their engineering needs. Aquatrol provides this data for informational purposes only and is not responsible for misuse or selection of internal parts.
