MED-MB SERIES

Mix Bed Exchange Resin

AQUATROL™ MB6040SG Mixed Bed Resin is a semi-conductor grade ion exchange mixed bed resin which has been designed for numerous applications, including final polishing in the highest purity water treatment applications. The AQUATROL™ MB6040SG Mixed Bed Resin is a pre-mixed resin product composed of an equivalent mixture of high capacity, fully regenerated strong acid, and strong base gel type ion exchange resins.

APPLICATIONS

Mixed Bed Resin is commonly used in applications where the highest level of water purity is required, such as in the production of electronics, pharmaceuticals, and medical devices. It is also used in laboratories and research facilities where pure water is essential for experiments and tests.

PRODUCT SPECIFICATIONS

Flow Rate of Regenerate Solution: 17.6-26.4 gpm (4-6 M/Hr)
Max. operating temperature: 140 °F
Feed water temperature: 60 to 77 °F (15 to 25 °C)
Min. bed depth: 3 feet (900 mm)
Service flow rate: 30 to 50 BV*/h

RECOMMENDED INFLUENT WATER QUALITY

Inlet Resistivity: > 17 MQ.cm
Inlet Silica: < 2 ppb
Inlet Total Organic Carbon: < 15 ppb

DATA SHEETS

MIX BED EXCHANGE SPECIFICATIONS

Part Number	Description	Bag
MED-MB6040SG	Aquatrol™ High Purity Mixed Bed Resin	1 cu. ft.
